Hercules®
SKU: 000-15135-001
000-15135-001Hercules® is a sailing processor built for sailors who demand more. It boasts greater accuracy, richer features, and better connectivity than ever before. Broad compatibility and advanced datasets give performance sailors the upper hand in competition. And a brand-new web interface allows for easy data recording and management for all.
Hercules® is designed to sit at the heart of an advanced sailing system. With an ultra-fast processor and maximised integration options, Hercules delivers an expanded suite of sailing data to B&G Nemesis™ displays, Vulcan™ or Zeus® Chartplotters. Data can be accessed via the B&G App or the all-new web interface, allowing recordings to be uploaded to the cloud, where it can be viewed, analysed, replayed and shared.
Enhanced Accuracy
Hercules is engineered for precision. Greater accuracy comes from advanced calculation options and calibration for true wind, with advanced heel and motion correction* improving boat speed calibration. Advanced Polar Tables and Target performance data help users achieve optimal performance and navigation. And racers get the upper hand with intelligent StartLine calculation.
*when paired with a motion sensor
Enhanced Accuracy
Hercules is engineered for precision. Greater accuracy comes from advanced calculation options and calibration for true wind, with advanced heel and motion correction* improving boat speed calibration. Advanced Polar Tables and Target performance data help users achieve optimal performance and navigation. And racers get the upper hand with intelligent StartLine calculation.
*when paired with a motion sensor
Fine Tune, Record & Review
With Hercules, sailing data can be recorded to an SD card, providing greater storage for custom data recording, which can be managed through the new, intuitive web interface – Advanced data recording also allows users to record custom events like sail changes and configurations for later analysis.
Fine Tune, Record & Review
With Hercules, sailing data can be recorded to an SD card, providing greater storage for custom data recording, which can be managed through the new, intuitive web interface – Advanced data recording also allows users to record custom events like sail changes and configurations for later analysis.
Features
Enhanced Accuracy
Record & Review
Maximised Integration
Maximised Integration
Built for use on serious cruising and racing yachts, Hercules supports dual wind sensors and rudders, on-board both mono- and multi-hull builds. With a guided on-boarding system and automated calibration for core sensors, set up and management is simple.
Hercules is NMEA2000 and Ethernet compatible and supports loadcell data along with third-party analytics services. It’s fully compatible with existing Triton™ 2, H5000, HV and Nemesis™ displays, H5000 Analogue and Serial modules, and the new Hercules Expansion module.
Maximised Integration
Built for use on serious cruising and racing yachts, Hercules supports dual wind sensors and rudders, on-board both mono- and multi-hull builds. With a guided on-boarding system and automated calibration for core sensors, set up and management is simple.
Hercules is NMEA2000 and Ethernet compatible and supports loadcell data along with third-party analytics services. It’s fully compatible with existing Triton™ 2, H5000, HV and Nemesis™ displays, H5000 Analogue and Serial modules, and the new Hercules Expansion module.
Key Features
- Latest quad-core microprocessor
- B&G® App Integration for data recording and review
- Web interface provides easy access to sailing data, system configuration and controls
- NMEA2000® compliant interface (micro-C)
- Dual Ethernet ports (100Mbps)
- 9 x 12-bit analogue channels
- 2 x Serial I/O channels
- 2 x Configurable alarm outputs
- 1 x Crew overboard input
- Micro SD card
- Built-in barometric pressure sensor
- 12/24V Power Supply
Related Items
Specifications
- Connectivity
- Ethernet Ports
- 2 x 100Mbit
- NMEA 0183 Sentences supported
- Input: HDG, HDT, ROT, THS, GGA, GLL, GSA, GSV, RMB, RMC, VTG, ZDA, AAM, APB, BWC, XTE, DPT, MTW, VHW, VLW, MWD, MWV, VDR, XDR. Output: HDG, HDT, THS, GGS, GLL, GSA, GSV, RMA, RMB, RMC, VTG, ZDA, AAM, APB, BOD, BWC, XTE, DPT, MTW, VHW, MWV, XDR.
- NMEA 2000 Connectivity
- 1 x NMEA 2000 Micro-C port, 1 LEN
- PC Connectivity
- 1x Ethernet (webserver)
- Approvals
- Approvals Compliance
- IEC/EN 60945
- Electrical
- Recommended Fuse Rating
- 3A
- Supply Voltage
- 12/24V DC (9.0 - 31V DC)
- Environment
- Operating Temperature Range
- -15 to +55ºC (+5 to +131ºF)
- Storage Temperature Range
- -40 to +85ºC (-40 to +185ºF)
- Waterproofrating
- IPX6 and IPX7
- Physical
- Compass Safe
- 500mm (19.6')
- Dimensions W x H x D
- 230 x 192 x 63mm (9 x 7.6 x 2.5")
- Mounting Type
- Surface Mount
- Weight
- 0.7 kg (1.5 lbs)
- Other
- Interface
- Webserver
- Warranty Period
- 2 years
